eCall

title eCall

eCall

eCall is an automatic emergency call system for vehicles that automatically dials 112 in the event of a serious accident and transmits important information such as location and time of accident to the relevant control center. The aim of this system is to get emergency services to the scene of an accident faster, reducing the number of road deaths and the consequences of accidents.

Technology

Vehicles with new type approval from 2018-04-01 must be equipped with eCall. The system is based on a navigation receiver installed in the vehicle via GPS and Galileo as well as 2G and 3G mobile communications and automatically triggers a telephone connection to the emergency number 112 after a serious accident. The emergency call system can also be triggered manually in the event of urgent medical problems. For this purpose, an SOS button is installed in the car, often located on the headliner. When triggered automatically or manually, the following data is transmitted:

NG eCall

Since eCall was designed in 2018 based on the 2G and 3G mobile communications standards, the shutdown of 3G in 2021 and 2G by the end of 2030 at the latest, there was a need for a more modern system. This is provided by Next Generation eCall, which uses the 4G and, in the future, the 5G mobile network. From 2026-01-01, cars with new type approval must have Next Generation eCall, and from 2027-01-01, all new vehicles must have it. In addition to the data already transmitted by eCall, Next Generation eCall can also transmit live images from the scene of the accident or health data of the occupants, if they have given their consent.

Legal

EU Directive 2015/758, which came into force in May 2015, required member states to introduce eCall.

Statistics

In 2024, 136,000 eCall emergency calls were triggered in Germany (source: >Telekom).
